Server-Sent Events (SSE) is a server push technology enabling a client to receive automatic updates from a server via an HTTP connection, and describes how servers can initiate data transmission towards clients once an initial client connection has been established. They are commonly used to send message updates or continuous data streams to a browser client and designed to enhance native, cross-browser streaming through a JavaScript API called EventSource, through which a client requests a particular URL in order to receive an event stream. The EventSource API is standardized as part of HTML Living Standard by the WHATWG. The media type for SSE is text/event-stream. All modern browsers support server-sent events: Firefox 6+, Google Chrome 6+, Opera 11.5+, Safari 5+, Microsoft Edge 79+, Brave. Since SSE does not use either persistent connections nor chunked transfer encoding, HTTP/1.1 is not a technical requirement. == History == The SSE mechanism was first specified by Ian Hickson as part of the "WHATWG Web Applications 1.0" proposal starting in 2004. In September 2006, the Opera web browser implemented the experimental technology in a feature called "Server-Sent Events". The W3C published Server-Sent Events as a Recommendation on February 3, 2015, after years of development through Working Drafts and Candidate Recommendations. == Example == == Technology == When sending high-frequency data , the server must manage backpressure to prevent saturating clients. This is mitigated in the following ways: Client-side buffering: Browsers have limited buffer space for incoming server-sent events Adaptive rate limiting: Servers can adjust event frequency and monitor connection health Event batching: Combining multiple events into larger and less frequent transmissions
Desktop Window Manager
Desktop Window Manager (DWM, previously Desktop Compositing Engine or DCE in builds of pre-reset Windows Longhorn) is the compositing window manager in Microsoft Windows since Windows Vista that enables the use of hardware acceleration to render the graphical user interface of Windows. It was originally created to enable portions of the new "Windows Aero" user experience, which allowed for effects such as transparency, 3D window switching and more. It is also included with Windows Server 2008, but requires the "Desktop Experience" feature and compatible graphics drivers to be installed. == Architecture == The Desktop Window Manager is a compositing window manager, meaning that each program has a buffer that it writes data to; DWM then composites each program's buffer into a final image. By comparison, the stacking window manager in Windows XP and earlier (and also Windows Vista and Windows 7 with Windows Aero disabled) comprises a single display buffer to which all programs write. DWM works in different ways depending on the operating system (Windows 7 or Windows Vista) and on the version of the graphics drivers it uses (WDDM 1.0 or 1.1). Under Windows 7 and with WDDM 1.1 drivers, DWM only writes the program's buffer to the video RAM, even if it is a graphics device interface (GDI) program. This is because Windows 7 supports (limited) hardware acceleration for GDI and in doing so does not need to keep a copy of the buffer in system RAM so that the CPU can write to it. Because the compositor has access to the graphics of all applications, it easily allows visual effects that string together visuals from multiple applications, such as transparency. DWM uses DirectX to perform the function of compositing and rendering in the GPU, freeing the CPU of the task of managing the rendering from the off-screen buffers to the display. However, it does not affect applications painting to the off-screen buffers – depending on the technologies used for that, this might still be CPU-bound. DWM-agnostic rendering techniques like GDI are redirected to the buffers by rendering the user interface (UI) as bitmaps. DWM-aware rendering technologies like WPF directly make the internal data structures available in a DWM-compatible format. The window contents in the buffers are then converted to DirectX textures. The desktop itself is a full-screen Direct3D surface, with windows being represented as a mesh consisting of two adjacent (and mutually inverted) triangles, which are transformed to represent a 2D rectangle. The texture, representing the UI chrome, is then mapped onto these rectangles. Window transitions are implemented as transformations of the meshes, using shader programs. With Windows Vista, the transitions are limited to the set of built-in shaders that implement the transformations. Greg Schechter, a developer at Microsoft has suggested that this might be opened up for developers and users to plug in their own effects in a future release. DWM only maps the primary desktop object as a 3D surface; other desktop objects, including virtual desktops as well as the secure desktop used by User Account Control are not. Because all applications render to an off-screen buffer, they can be read off the buffer embedded in other applications as well. Since the off-screen buffer is constantly updated by the application, the embedded rendering will be a dynamic representation of the application window and not a static rendering. This is how the live thumbnail previews and Windows Flip work in Windows Vista and Windows 7. DWM exposes a public API that allows applications to access these thumbnail representations. The size of the thumbnail is not fixed; applications can request the thumbnails at any size - smaller than the original window, at the same size or even larger - and DWM will scale them properly before returning. Aero Flip does not use the public thumbnail APIs as they do not allow for directly accessing the Direct3D textures. Instead, Aero Flip is implemented directly in the DWM engine. The Desktop Window Manager uses Media Integration Layer (MIL), the unmanaged compositor which it shares with Windows Presentation Foundation, to represent the windows as composition nodes in a composition tree. The composition tree represents the desktop and all the windows hosted in it, which are then rendered by MIL from the back of the scene to the front. Since all the windows contribute to the final image, the color of a resultant pixel can be decided by more than one window. This is used to implement effects such as per-pixel transparency. DWM allows custom shaders to be invoked to control how pixels from multiple applications are used to create the displayed pixel. The DWM includes built-in Pixel Shader 2.0 programs which compute the color of a pixel in a window by averaging the color of the pixel as determined by the window behind it and its neighboring pixels. These shaders are used by DWM to achieve the blur effect in the window borders of windows managed by DWM, and optionally for the areas where it is requested by the application. Since MIL provides a retained mode graphics system by caching the composition trees, the job of repainting and refreshing the screen when windows are moved is handled by DWM and MIL, freeing the application of the responsibility. The background data is already in the composition tree and the off-screen buffers and is directly used to render the background. In pre-Vista Windows OSs, background applications had to be requested to re-render themselves by sending them the WM_PAINT message. DWM uses double-buffered graphics to prevent flickering and tearing when moving windows. The compositing engine uses optimizations such as culling to improve performance, as well as not redrawing areas that have not changed. Because the compositor is multi-monitor aware, DWM natively supports this too. During full-screen applications, such as games, DWM does not perform window compositing and therefore performance will not appreciably decrease. On Windows 8 and Windows Server 2012, DWM is used at all times and cannot be disabled, due to the new "start screen experience" implemented. Since the DWM process is usually required to run at all times on Windows 8, users experiencing an issue with the process are seeing memory usage decrease after a system reboot. This is often the first step in a long list of troubleshooting tasks that can help. It is possible to prevent DWM from restarting temporarily in Windows 8, which causes the desktop to turn black, the taskbar grey, and break the start screen/modern apps, but desktop apps will continue to function and appear just like Windows 7 and Vista's Basic theme, based on the single-buffer renderer used by XP. They also use Windows 8's centered title bar, visible within Windows PreInstallation Environment. Starting up Windows without DWM will not work because the default lock screen requires DWM unlike the fallback lockscreen that appears as a command line interface program when Windows.UI.Logon.dll isn't present on Windows versions such as 1507 and later, so it can only be done on the fly, and does not have any practical purposes. Starting with Windows 10, disabling DWM in such a way will cause the entire compositing engine to break, even traditional desktop apps, due to Universal App implementations in the taskbar and new start menu. Windows can still be partially usable without the presence of DWM but requires Sihost.exe to not be present due to it relying on DWM. Most of the applications in Windows 11 require DWM to render UI elements and transparency, Windows 11's new task manager requires dwm to render menus unlike the fallback -d version. Unlike its predecessors, Windows 8 supports basic display adapters through Windows Advanced Rasterization Platform (WARP), which uses software rendering and the CPU to render the interface rather than the graphics card. This allows DWM to function without compatible drivers, but not at the same level of performance as with a normal graphics card. DWM on Windows 8 also adds support for stereoscopic 3D. == Redirection == For rendering techniques that are not DWM-aware, output must be redirected to the DWM buffers. With Windows, either GDI or DirectX can be used for rendering. To make these two work with DWM, redirection techniques for both are provided. With GDI, which is the most used UI rendering technique in Microsoft Windows, each application window is notified when it or a part of it comes in view and it is the job of the application to render itself. Without DWM, the rendering rasterizes the UI in a buffer in video memory, from where it is rendered to the screen. Under DWM, GDI calls are redirected to use the Canonical Display Driver (cdd.dll), a software renderer. A buffer equal to the size of the window is allocated in system memory and CDD.DLL outputs to this buffer rather than the video memory. Another buffer is allocated in the video memory to represent t
The Visualization Handbook
The Visualization Handbook is a textbook by Charles D. Hansen and Christopher R. Johnson that serves as a survey of the field of scientific visualization by presenting the basic concepts and algorithms in addition to a current review of visualization research topics and tools. It is commonly used as a textbook for scientific visualization graduate courses. It is also commonly cited as a reference for scientific visualization and computer graphics in published papers, with almost 500 citations documented on Google Scholar. == Table of Contents == PART I - Introduction Overview of Visualization - William J. Schroeder and Kenneth M. Martin PART II - Scalar Field Visualization: Isosurfaces Accelerated Isosurface Extraction Approaches -Yarden Livnat Time-Dependent Isosurface Extraction - Han-Wei Shen Optimal Isosurface Extraction - Paolo Cignoni, Claudio Montani, Robert Scopigno, and Enrico Puppo Isosurface Extraction Using Extrema Graphs - Takayuki Itoh and Koji Koyamada Isosurfaces and Level-Sets - Ross Whitaker PART III - Scalar Field Visualization: Volume Rendering Overview of Volume Rendering - Arie E. Kaufman and Klaus Mueller Volume Rendering Using Splatting - Roger Crawfis, Daqing Xue, and Caixia Zhang Multidimensional Transfer Functions for Volume Rendering - Joe Kniss, Gordon Kindlmann, and Charles D. Hansen Pre-Integrated Volume Rendering - Martin Kraus and Thomas Ertl Hardware-Accelerated Volume Rendering - Hanspeter Pfister PART IV - Vector Field Visualization Overview of Flow Visualization - Daniel Weiskopf and Gordon Erlebacher Flow Textures: High-Resolution Flow Visualization - Gordon Erlebacher, Bruno Jobard, and Daniel Weiskopf Detection and Visualization of Vortices - Ming Jiang, Raghu Machiraju, and David Thompson PART V - Tensor Field Visualization Oriented Tensor Reconstruction - Leonid Zhukov and Alan H. Barr Diffusion Tensor MRI Visualization - Song Zhang, David Laidlaw, and Gordon Kindlmann Topological Methods for Flow Visualization - Gerik Scheuermann and Xavier Tricoche PART VI - Geometric Modeling for Visualization 3D Mesh Compression - Jarek Rossignac Variational Modeling Methods for Visualization - Hans Hagen and Ingrid Hotz Model Simplification - Jonathan D. Cohen and Dinesh Manocha PART VII - Virtual Environments for Visualization Direct Manipulation in Virtual Reality - Steve Bryson The Visual Haptic Workbench - Milan Ikits and J. Dean Brederson Virtual Geographic Information Systems - William Ribarsky Visualization Using Virtual Reality - R. Bowen Loftin, Jim X. Chen, and Larry Rosenblum PART VIII - Large-Scale Data Visualization Desktop Delivery: Access to Large Datasets - Philip D. Heermann and Constantine Pavlakos Techniques for Visualizing Time-Varying Volume Data - Kwan-Liu Ma and Eric B. Lum Large-Scale Data Visualization and Rendering: A Problem-Driven Approach - Patrick McCormick and James Ahrens Issues and Architectures in Large-Scale Data Visualization - Constantine Pavlakos and Philip D. Heermann Consuming Network Bandwidth with Visapult - Wes Bethel and John Shalf PART IX - Visualization Software and Frameworks The Visualization Toolkit - William J. Schroeder and Kenneth M. Martin Visualization in the SCIRun Problem-Solving Environment - David M. Weinstein, Steven Parker, Jenny Simpson, Kurt Zimmerman, and Greg M. Jones Numerical Algorithms Group IRIS Explorer - Jeremy Walton AVS and AVS/Express - Jean M. Favre and Mario Valle Vis5D, Cave5D, and VisAD - Bill Hibbard Visualization with AVS - W. T. Hewitt, Nigel W. John, Matthew D. Cooper, K. Yien Kwok, George W. Leaver, Joanna M. Leng, Paul G. Lever, Mary J. McDerby, James S. Perrin, Mark Riding, I. Ari Sadarjoen, Tobias M. Schiebeck, and Colin C. Venters ParaView: An End-User Tool for Large-Data Visualization - James Ahrens, Berk Geveci, and Charles Law The Insight Toolkit: An Open-Source Initiative in Data Segmentation and Registration - Terry S. Yoo amira: A Highly Interactive System for Visual Data Analysis - Detlev Stalling, Malte Westerhoff, and Hans-Christian Hege PART X - Perceptual Issues in Visualization Extending Visualization to Perceptualization: The Importance of Perception in Effective Communication of Information - David S. Ebert Art and Science in Visualization - Victoria Interrante Exploiting Human Visual Perception in Visualization - Alan Chalmers and Kirsten Cater PART XI - Selected Topics and Applications Scalable Network Visualization - Stephen G. Eick Visual Data-Mining Techniques - Daniel A. Keim, Mike Sips, and Mihael Ankerst Visualization in Weather and Climate Research - Don Middleton, Tim Scheitlin, and Bob Wilhelmson Painting and Visualization - Robert M. Kirby, Daniel F. Keefe, and David Laidlaw Visualization and Natural Control Systems for Microscopy - Russell M. Taylor II, David Borland, Frederick P. Brooks, Jr., Mike Falvo, Kevin Jeffay, Gail Jones, David Marshburn, Stergios J. Papadakis, Lu-Chang Qin, Adam Seeger, F. Donelson Smith, Dianne Sonnenwald, Richard Superfine, Sean Washburn, Chris Weigle, Mary Whitton, Leandra Vicci, Martin Guthold, Tom Hudson, Philip Williams, and Warren Robinett Visualization for Computational Accelerator Physics - Kwan-Liu Ma, Greg Schussman, and Brett Wilson
Overcast (app)
Overcast is a podcast app for iOS that was launched in 2014 by founder and operator Marco Arment. == Founder and operator == Arment was also the Chief Technology Officer of Tumblr and founder of Instapaper before founding Overcast, and he had created his own podcasts before launching the app. In March 2023, Arment told The Vergecast how he built and maintains Overcast by himself, and that he uses ad banners promoting podcasts to cover the costs of the free app. == Features and reception == In 2014, Overcast received positive reviews from MacWorld and iMore. In 2015, The Verge and The Sweet Setup each named it the best podcast app for iOS that year. In 2017, Discover Pods gave an endorsement citing the "smart speed" feature, which shortens quiet gaps in a podcast. In April 2019, Overcast introduced a feature that allowed users to share clips from podcasts to social media. In January 2020, Overcast was updated to allow users to skip the intros and outros of podcasts.
JotterPad
JotterPad is a text editor app for Android, developed by Two App Studio. It is proprietary software that uses the freemium pricing strategy. == Features == Jotterpad supports the markdown and fountain markup languages. Among its features are themes, synchronisation with Google Drive and Dropbox, dictionary and thesaurus, and snapshots. JotterPad uses a freemium pricing model, which means that a restricted version of the app is offered for free, while access to additional functionality requires payment. About half of the features are available in the free version. The synchronisation feature was originally limited to one account, and in Jotterpad 12 the option to synchronise using multiple accounts was added as a monthly subscription service.
Aggregation (linguistics)
In linguistics, aggregation is a subtask of natural language generation, which involves merging syntactic constituents (such as sentences and phrases) together. Sometimes aggregation can be done at a conceptual level. == Examples == A simple example of syntactic aggregation is merging the two sentences John went to the shop and John bought an apple into the single sentence John went to the shop and bought an apple. Syntactic aggregation can be much more complex than this. For example, aggregation can embed one of the constituents in the other; e.g., we can aggregate John went to the shop and The shop was closed into the sentence John went to the shop, which was closed. From a pragmatic perspective, aggregating sentences together often suggests to the reader that these sentences are related to each other. If this is not the case, the reader may be confused. For example, someone who reads John went to the shop and bought an apple may infer that the apple was bought in the shop; if this is not the case, then these sentences should not be aggregated. == Algorithms and issues == Aggregation algorithms must do two things: Decide when two constituents should be aggregated Decide how two constituents should be aggregated, and create the aggregated structure The first issue, deciding when to aggregate, is poorly understood. Aggegration decisions certainly depend on the semantic relations between the constituents, as mentioned above; they also depend on the genre (e.g., bureaucratic texts tend to be more aggregated than instruction manuals). They probably should depend on rhetorical and discourse structure. The literacy level of the reader is also probably important (poor readers need shorter sentences). But we have no integrated model which brings all these factors together into a single algorithm. With regard to the second issue, there have been some studies of different types of aggregation, and how they should be carried out. Harbusch and Kempen describe several syntactic aggregation strategies. In their terminology, John went to the shop and bought an apple is an example of forward conjunction Reduction Much less is known about conceptual aggregation. Di Eugenio et al. show how conceptual aggregation can be done in an intelligent tutoring system, and demonstrate that performing such aggregation makes the system more effective (and that conceptual aggregation make a bigger impact than syntactic aggregation). == Software == Unfortunately there is not much software available for performing aggregation. However the SimpleNLG system does include limited support for basic aggregation. For example, the following code causes SimpleNLG to print out The man is hungry and buys an apple.
Kinematic chain
In mechanical engineering, a kinematic chain is an assembly of rigid bodies connected by joints to provide constrained motion that is the mathematical model for a mechanical system. As the word chain suggests, the rigid bodies, or links, are constrained by their connections to other links. An example is the simple open chain formed by links connected in series, like the usual chain, which is the kinematic model for a typical robot manipulator. Mathematical models of the connections, or joints, between two links are termed kinematic pairs. Kinematic pairs model the hinged and sliding joints fundamental to robotics, often called lower pairs and the surface contact joints critical to cams and gearing, called higher pairs. These joints are generally modeled as holonomic constraints. A kinematic diagram is a schematic of the mechanical system that shows the kinematic chain. The modern use of kinematic chains includes analysis of Linkages (mechanical), compliance that arises from flexure joints in precision mechanisms, link compliance in compliant mechanisms and micro-electro-mechanical systems, and cable compliance in cable robotic and tensegrity systems. == Mobility formula == The degrees of freedom, or mobility, of a kinematic chain is the number of parameters that define the configuration of the chain. A system of n rigid bodies moving in space has 6n degrees of freedom measured relative to a fixed frame. This frame is included in the count of bodies, so that mobility does not depend on link that forms the fixed frame. This means the degree-of-freedom of this system is M = 6(N − 1), where N = n + 1 is the number of moving bodies plus the fixed body. Joints that connect bodies impose constraints. Specifically, hinges and sliders each impose five constraints and therefore remove five degrees of freedom. It is convenient to define the number of constraints c that a joint imposes in terms of the joint's freedom f, where c = 6 − f. In the case of a hinge or slider, which are one-degree-of-freedom joints, have f = 1 and therefore c = 6 − 1 = 5. The result in general where d {\displaystyle d} is the degrees of freedom for the mobility of a kinematic chain formed from n moving links and j joints each with freedom fi, i = 1, 2, …, j, is given by M = d n − ∑ i = 1 j ( d − f i ) = d ( N − 1 − j ) + ∑ i = 1 j f i {\displaystyle M=dn-\sum _{i=1}^{j}(d-f_{i})=d(N-1-j)+\sum _{i=1}^{j}f_{i}} Where N is the total number of links and includes the fixed link. Spacial linkages used d = 6 {\displaystyle d=6} and planar linkages use d = 3 {\displaystyle d=3} . This result is known as the Chebychev–Grübler–Kutzbach criterion. == Analysis of kinematic chains == The constraint equations of a kinematic chain couple the range of movement allowed at each joint to the dimensions of the links in the chain, and form algebraic equations that are solved to determine the configuration of the chain associated with specific values of input parameters, called degrees of freedom. The constraint equations for a kinematic chain are obtained using rigid transformations [Z] to characterize the relative movement allowed at each joint and separate rigid transformations [X] to define the dimensions of each link. In the case of a serial open chain, the result is a sequence of rigid transformations alternating joint and link transformations from the base of the chain to its end link, which is equated to the specified position for the end link. A chain of n links connected in series has the kinematic equations, [ T ] = [ Z 1 ] [ X 1 ] [ Z 2 ] [ X 2 ] ⋯ [ X n − 1 ] [ Z n ] , {\displaystyle [T]=[Z_{1}][X_{1}][Z_{2}][X_{2}]\cdots [X_{n-1}][Z_{n}],\!} where [T] is the transformation locating the end-link—notice that the chain includes a "zeroth" link consisting of the ground frame to which it is attached. These equations are called the forward kinematics equations of the serial chain. Kinematic chains of a wide range of complexity are analyzed by equating the kinematics equations of serial chains that form loops within the kinematic chain. These equations are often called loop equations. The complexity (in terms of calculating the forward and inverse kinematics) of the chain is determined by the following factors: Its topology: a serial chain, a parallel manipulator, a tree structure, or a graph. Its geometrical form: how are neighbouring joints spatially connected to each other? Explanation Two or more rigid bodies in space are collectively called a rigid body system. We can hinder the motion of these independent rigid bodies with kinematic constraints. Kinematic constraints are constraints between rigid bodies that result in the decrease of the degrees of freedom of rigid body system. == Synthesis of kinematic chains == The constraint equations of a kinematic chain can be used in reverse to determine the dimensions of the links from a specification of the desired movement of the system. This is termed kinematic synthesis. Perhaps the most developed formulation of kinematic synthesis is for four-bar linkages, which is known as Burmester theory. Ferdinand Freudenstein is often called the father of modern kinematics for his contributions to the kinematic synthesis of linkages beginning in the 1950s. His use of the newly developed computer to solve Freudenstein's equation became the prototype of computer-aided design systems. This work has been generalized to the synthesis of spherical and spatial mechanisms.
